Product name: Copper core conductor B-grade flame retardant polyvinyl chloride insulation and polyvinyl chloride sheathed power cable

Model specifications: ZB-VV 3X16 square meters

Rated voltage: 0.6/1KV

Implementation standard: GB/T 12706.1-2008;

Product color: black

Product length: 10 meters ruling (cables with small cross-sectional area, such as 1.5 square meters - 6 square meters, not made in the factory, only for display)

The number of cores includes: single core, 2 core, 3 core, 4 core, 5 core, 3+1 core, 3+2 core, 4+1 core;

Product structure: The components from the inside out are conductor, insulating layer, filling layer, (steel strip layer), and sheath layer. The commonly used conductor materials on the market today are of course copper conductors; the insulating layer and outer sheathing materials are polyvinyl chloride, i.e. PVC plastic; the filling layer is generally softer nylon material to prevent the cable from being between the conductors inside the cable. Direct contact with each other and extrude; the VV cables of steel tape armor are VV22 cables, and the function of steel tape armor is to resist compression and can be used for burial.

Product purpose: It is generally used as a power transmission hub, often buried in soil or laid in indoors, in channels, and tunnels. The insulation distance between lines is small, no poles and towers are used, and it occupies little land and basically does not occupy space on the ground.
