This product according to the the People's Republic of China national standard GB/T9330.2-2008, GB/T9330.3-2008 manufacturing.
450/750V and below
Product specification: 2-61 core, 1.5-10mm ²
1. Power frequency rated voltage Uo/U is 450/750V.
2. The maximum allowable long-term working temperature of the cable conductor is 70 ℃.
3. The ambient temperature during cable laying shall not be lower than 0 ℃.
4, the cable recommend allows the bending radius: unarmored cable should not be less than 6 times the outer diameter of the cable; armored or copper shielded cable, should not be less than 12 times the outer diameter of the cable; shielded flexible cable, should not be less than 6 times the outer diameter of the cable.
| Model | Product Name | Use occasion |
|
KVV
|
PVC insulated PVC sheathed control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KVVP
|
PVC insulated PVC sheathed braided shield control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KVV22
|
PVC insulated PVC sheathed steel tape armored control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KVVP2
|
PVC insulated PVC sheathed copper tape shielded control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KVVP2-22
|
PVC insulated PVC sheathed copper tape shielded steel tape armored control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KYJV
|
XLPE insulated PVC sheathed control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KYJVP
|
XLPE insulated PVC sheathed copper wire braided shield control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KYJV22
|
XLPE insulated PVC sheathed steel tape armored control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KYJVP2
|
XLPE insulated PVC sheathed copper tape shielded control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
|
KYJVP2-22
|
XLPE insulated PVC sheathed copper tape shielded steel tape armored control cable
|
Used for 450/750V and below control, monitoring circuit and protection circuit and other occasions
|
