This product is in accordance with the company's enterprise standard MT/T 386-2011,Q/YT 012-2019 Mfg.
1. Power frequency rated voltage Uo/U is 450/750V.
2. The maximum allowable long-term working temperature of the cable conductor is 90 ℃.
3. The ambient temperature during cable laying shall not be lower than 0 ℃.
4, the cable recommend allows the bending radius: unarmored cable should not be less than 6 times the outer diameter of the cable; armored or copper shielded cable, should not be less than 12 times the outer diameter of the cable; shielded flexible cable, should not be less than 6 times the outer diameter of the cable.
| Model | Product Name | Voltage class/specification |
|
MKYJV
|
Coal mine XLPE insulated PVC sheathed control cable
|
0.45/0.75kV;(2-14)x(4-6)
|
|
MKYJV
|
Coal mine XLPE insulated PVC sheathed control cable
|
0.45/0.75kV;(2x10)x10
|
|
MKYJV
|
Coal mine XLPE insulated PVC sheathed control cable
|
0.45/0.75kV;(2-61)x(0.75-2.5)
|
|
MKYJV22
|
Coal mine XLPE insulated PVC sheathed steel tape armored control cable
|
0.45/0.75kV;(4-10)x10
|
|
MKYJV22
|
Coal mine XLPE insulated PVC sheathed steel tape armored control cable
|
0.45/0.75kV;(7-61)x(0.75-1.5)
|
|
MKYJV22
|
Coal mine XLPE insulated PVC sheathed steel tape armored control cable
|
0.45/0.75kV;(4-14)x(4-6)
|
|
MKYJV22
|
Coal mine XLPE insulated PVC sheathed steel tape armored control cable
|
0.45/0.75kV;(4-61)x2.5
|
|
MKYJVP
|
Coal mine XLPE insulated PVC sheathed copper wire braided shield control cable
|
0.45/0.75kV;(2x10)x10
|
|
MKYJVP
|
Coal mine XLPE insulated PVC sheathed copper wire braided shield control cable
|
0.45/0.75kV;(2-14)x(4-6)
|
|
MKYJVR
|
Coal mine XLPE insulated PVC sheathed control flexible cable
|
0.45/0.75kV;(2-61)x(0.75-2.5)
|
|
MKYJVP
|
Coal mine XLPE insulated PVC sheathed copper wire braided shield control cable
|
0.45/0.75kV;(2-61)x(0.75-2.5)
|
|
MKYJVRP
|
Coal mine XLPE insulated PVC sheathed copper wire braided shield control flexible cable
|
0.45/0.75kV;(2-61)x(0.75-2.5)
|
