PLACE： HOME > Product > Mining cable
This product is in accordance with the company's enterprise standard MT/T 818.13-Manufacture of 2009.
1. Power frequency rated voltage U0/U: 1.8/3kV
2. Maximum allowable working temperature of cable conductor: 90 ℃.
3. The maximum temperature of the cable conductor shall not exceed 250 ℃ during short circuit (the longest time shall not exceed 5s).
4. The ambient temperature during cable laying shall not be lower than 0 ℃.
5, cable bending radius: three-core cable is not less than 15 times the outer diameter of the cable; single-core cable is not less than 21 times the outer diameter of the cable.
| Model | Product Name | Voltage class/specification |
|
MYJV
|
Coal mine XLPE insulated PVC sheathed power cable
|
0.6/1kV;1.5-300
|
|
MYJV
|
Coal mine XLPE insulated PVC sheathed power cable
|
1.8/3kV;10-300
|
|
MYJV
|
Coal mine XLPE insulated PVC sheathed power cable
|
3.6/6kV;25-300
|
|
MYJV
|
Coal mine XLPE insulated PVC sheathed power cable
|
6/6kV;25-300
|
|
MYJV
|
Coal mine XLPE insulated PVC sheathed power cable
|
6/10kV;25-300
|
|
MYJV
|
Coal mine XLPE insulated PVC sheathed power cable
|
8.7/10kV;25-300
|
|
MYJV22
|
Coal mine XLPE insulated steel tape armored PVC sheathed power cable
|
0.6/1kV;2.5-300
|
|
MYJV22
|
Coal mine XLPE insulated steel tape armored PVC sheathed power cable
|
1.8/3kV;10-300
|
|
MYJV22
|
Coal mine XLPE insulated steel tape armored PVC sheathed power cable
|
3.6/6kV;25-300
|
|
MYJV22
|
Coal mine XLPE insulated steel tape armored PVC sheathed power cable
|
6/6kV;25-300
|
|
MYJV22
|
Coal mine XLPE insulated steel tape armored PVC sheathed power cable
|
6/10kV;25-300
|
|
MYJV22
|
Coal mine XLPE insulated steel tape armored PVC sheathed power cable
|
8.7/10kV;25-300
|
|
MYJV32
|
Coal mine XLPE insulated fine steel wire armored PVC sheathed power cable
|
0.6/1kV;16-300
|
|
MYJV32
|
Coal mine XLPE insulated fine steel wire armored PVC sheathed power cable
|
3.6/6kV;25-300
|
|
MYJV32
|
Coal mine XLPE insulated fine steel wire armored PVC sheathed power cable
|
6/6kV;25-300
|
|
MYJV32
|
Coal mine XLPE insulated fine steel wire armored PVC sheathed power cable
|
6/10kV;25-300
|
|
MYJV32
|
Coal mine XLPE insulated fine steel wire armored PVC sheathed power cable
|
8.7/10kV;25-300
|
|
MYJV42
|
Coal mine XLPE insulated thick steel wire armored PVC sheathed power cable
|
0.6/1kV;50-240
|
|
MYJV42
|
Coal mine XLPE insulated thick steel wire armored PVC sheathed power cable
|
3.6/6kV;50-240
|
|
MYJV42
|
Coal mine XLPE insulated thick steel wire armored PVC sheathed power cable
|
6/6kV;50-240
|
|
MYJV42
|
Coal mine XLPE insulated thick steel wire armored PVC sheathed power cable
|
6/10kV;50-240
|
|
MYJV42
|
Coal mine XLPE insulated thick steel wire armored PVC sheathed power cable
|
8.7/10kV;50-240
|
