This product adopts the People's Republic of China national standard GB/T12706.3-2008 standard for production.
Voltage level: suitable for rated voltage 21/35kV, 26/35kV
Product specifications: 1, 3 core, 50-630mm ²
**Allowable working temperature of cable conductor: 90 ℃
The maximum temperature of the cable conductor shall not exceed 250 ℃ during short circuit (the longest time shall not exceed 5s)
Ambient temperature during cable laying shall not be lower than 0 ℃
Cable bending radius: three-core cable is not less than 15 times the outer diameter of the cable; single-core cable is not less than 20 times the outer diameter of the cable
| Model | Product Name | Use scope |
|
YJV 21/35kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 21/35kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV 26/35kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 26/35kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
