this product according to the the People's Republic of China national standard GB/T12706. 2-2008 Manufacture.
Voltage level: suitable for rated voltage level 3.6/6kV, 6/10kV, 8.7/15kV, 12/20kV, 18/30kV
product specifications: 1, 3 core , 10-630mm ²
Cable conductor **allowable working temperature: 90 ℃
Short circuit (the longest time does not exceed 5s) cable conductor maximum temperature does not exceed 250 ℃
Cable laying environment temperature should not be lower than 0 ℃
Cable bending radius: three-core cable not less than cable diameter 15 times; single-core cable not less than cable diameter 20 times
| Model | Product Name | Use occasion |
|
YJV 3.6/6kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 3.6/6kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV 6/10kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 6/10kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV 8.7/15kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 8.7/15kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV 12/20kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 12/20kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV 18/30kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 18/30kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
