This product according to the the People's Republic of China national standard GB/T12706.1-2008 manufacturing.
Voltage level: suitable for rated voltage level 0.6/1kV
Product specifications: 1-5 core, 1.5-630mm ²
Power frequency rated voltage U0/U: 0.6/1kV
Cable conductor **allowable working temperature: 90 ℃
Short circuit (the longest time does not exceed 5s) cable conductor maximum temperature does not exceed 250 ℃
Cable laying environment temperature should not be lower than 0 ℃
Cable bending radius: not less than cable diameter 20 times
| Model | Product Name | Use occasion |
|
YJV 0.6/1kV
|
XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJLV 0.6/1kV
|
Aluminum conductor XLPE insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJV22 0.6/1kV
|
XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJY23 0.6/1kV
|
XLPE insulated steel tape armored non-halogen low smoke polyolefin sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
YJLV22 0.6/1kV
|
Aluminum conductor XLPE insulated steel tape armored PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
|
EYR 0.6/1kV
|
Copper conductor ethylene propylene rubber insulated PVC sheathed power cable
|
The product is suitable for distribution networks or industrial installations.
|
